CGH: Design Overview

Whitworth's (1981) Isothermal Free-Energy Surface
|   Tiled Menu   |   Tables of Content   |  Banner Video   |  Tohline Home Page   |


Here we outline a research project that builds upon the extraordinary work of Huebschman, Manjuluri, & Garner (2003) titled, Dynamic holographic 3-D image projection.

hologram Photo focused on LSU logo Photo focused on Louisiana seal

The objective is to create a fully three-dimensional (3D) rendering of the time-dependent surface of an object in 3-space, using efficiently calculated, two-dimensional digital holographic images. This will be accomplished by bouncing a monochromatic beam of light — the light source being, for example, an R, G, or B laser — off of a two-dimensional (2D) array of identical, small, rectangular mirrors such as the mirror configuration that provides the central functional element of Texas Instrument's DLP chip. Each mirror will be uniformly illuminated, but the brightness of the light that is incident on each mirror will, in general, vary from mirror to mirror. Ultimately, the desired 3D image will be constructed by adding together the diffraction patterns that are generated separately, but simultaneously, by all of the small mirrors in the array.

Slit Diffraction

Single Aperture

Figure 1
Chapter1Fig1

As has been detailed in an accompanying discussion, we examine, first, the amplitude (and phase) of light which, after passing through an aperture of width ~w = (Y_1 - Y_2) = 2c, is incident on an image screen that is parallel to, and located a distance ~Z from, the aperture. The amplitude at any location, ~y_1, along the image screen is given by the expression,

~A(y_1)

~=

~\sum_j
\beta_j \biggl[ \cos\biggl(\frac{2\pi D_j}{\lambda} + \phi_j \biggr) + i   \sin\biggl(\frac{2\pi D_j}{\lambda} + \phi_j \biggr) \biggr]
\, ,

where, ~\beta_j = \beta(Y_j) is the specified brightness at each "j" point along the illuminated aperture,

~D_j

~=

~
L \biggl[1 - \frac{2y_1 Y_j}{L^2} + \frac{Y_j^2}{L^2} \biggr]^{1 / 2} \, ,

and,

~L

~\equiv

~
[Z^2 + y_1^2  ]^{1 / 2} \, .

The green solid curves in Figures 2 & 3 of our accompanying, more detailed discussion display — for a fixed set of values of the parameter-pair, ~(\lambda, w) — how the amplitude of the incident light, ~(A\cdot A^*)^{1 / 2}, varies across an image screen that is placed at two different distances from the aperture.

Notice that, in the definition of ~D_j, the expression inside the square brackets involves a term that depends quadratically on the dimensionless length scale, ~Y_j/L, as well as a term that depends linearly on this ratio. As discussed below, our expression for the amplitude simplifies nicely in situations where the quadratic term can be ignored. (The red dotted curves in Figures 2 & 3 of our accompanying discussion illustrate how the image-screen diffraction pattern is altered as a result of this simplification.) Via a related simplification, we also will find that the various natural lengths of this problem can be related to one another via the expression,

~y_1\biggr|_{1^\mathrm{st} \mathrm{fringe}} = \frac{L \Delta y_1}{c}

~\approx

~\frac{\lambda Z}{2c} \, .

CAUTION: Be sure that the "L" in these various expressions is, indeed, always the same quantity.

Simplifications

If we assume that everywhere along the aperture the phase ~\phi_j = 0 and if, furthermore, we assume that, for all ~j,

~\biggl| \frac{Y_j}{L}\biggr| \ll 1 \, ,

we can drop the quadratic term in favor of the linear one in the above expression for ~D_j and deduce that,

~A(y_1)

~\approx

~e^{i2\pi L/\lambda} \sum_j
\beta_j \biggl[ \cos\biggl(\frac{2\pi y_1 Y_j}{\lambda L} \biggr) - i  \sin\biggl(\frac{2\pi y_1 Y_j}{\lambda L} \biggr) \biggr]
\, .

Let's consider the case of a (single) aperture of width, ~w = 2c, that is uniformly illuminated — that is, ~\beta is independent of location across the aperture. If we allow the summation index, ~j, to go to infinity, this (simplified) amplitude expression can be integrated to give, at various discrete ~(n) locations along the image screen,

~A(n \Delta y_1)

~=

~
e^{i2\pi L_n/\lambda} \biggl[ a_n + i b_n\biggr] \, ,

where (see the associated Example #2 discussion),

~a_n

~=

~\frac{\beta}{2c} \int_{-c}^c \cos\biggl( \frac{2\pi n \Delta y_1 x}{\lambda L_n} \biggr) dx

~=

~\beta \biggl[
\frac{\sin\theta_n }{\theta_n}
\biggr] \, ,

~b_n

~=

~-~\frac{\beta}{2c} \int_{-c}^c \sin\biggl( \frac{2\pi n \Delta y_1 x}{\lambda L_n} \biggr) dx

~=

~0\, ,

~\theta_n

~\equiv

~\frac{2\pi n \Delta y_1 c}{\lambda L_n} \, .
